Evolution mechanism of unmanned cluster cooperation oriented toward strategy selection diversity

doi:10.23919/JSEE.2025.000017

Journal of Systems Engineering and Electronics ›› 2025, Vol. 36 ›› Issue (2): 462-482.doi: 10.23919/JSEE.2025.000017

• SYSTEMS ENGINEERING • Previous Articles

Evolution mechanism of unmanned cluster cooperation oriented toward strategy selection diversity

Zhenhai XIE¹^,²(), Minggang YU¹(), Ming HE¹^,*(), Guoyou CHEN¹(), Zheng ZHAI¹(), Ziyu WANG¹^,²(), Lu LIU¹()

¹ Institute of Command and Control Engineering, Army Engineering University of PLA, Nanjing 210007, China
² Unit 31630 of the Chinese People’s Liberation Army, Huizhou 516000, China

Received:2023-01-03 Online:2025-04-18 Published:2025-05-20
Contact: Ming HE E-mail:529486527@qq.com;yuminggang8989@163.com;paper_review@126.com;549862832@qq.com;zhai-zhengreview@foxmail.com;2228370591@qq.com;305485177@qq.com
About author:
XIE Zhenhai was born in 1988. He received his B.S. degree in computer science and technology from Yangtze University, in 2009 and M.S. degree in command and control engineering from Army Engineering University of PLA in 2023. His research interest is unmanned command and control. E-mail: 529486527@qq.com

YU Minggang was born in 1986. He received his B.S. degree in the School of Information Engineering from Wuhan University of Technology in 2009, and M.S. and Ph.D. degrees from Science of Military Command, Army Engineering University of PLA in 2016. He is an associate professor of Institute of Command and Control Engineering, Army Engineering University of PLA. His research interests include game theory and complex network. E-mail: yuminggang8989@163.com

HE Ming was born in 1978. He received his B.S., M.S. and Ph.D. degrees in science of military command from Army Engineering University of PLA in 2001, 2004 and 2008, respectively. He is currently a professor of Command and Control Engineering College, Army Engineering University of PLA. His research interest is unmanned command and control. E-mail: paper_review@126.com

CHEN Guoyou was born in 1971. He received M.S. degree in science of military command from Army Engineering University of PLA in 1999. He is an associate professor of Institute of Communication Engineering, Army Engineering University of PLA. His research interests include communication engineering. E-mail: 549862832@qq.com

ZHAI Zheng was born in 1984. He received his B.S. and M.S. degrees in command and control engineering from Army Engineering University of PLA in 2006 and 2023, respectively. His research interest is UAV mission planning. E-mail: zhai-zhengreview@foxmail.com

WANG Ziyu was born in 2000. He received his B.S. degree in defense engineering from Army University of Engineering of PLA in 2022. His research interests include deep lerning and intelligent control. E-mail: 2228370591@qq.com

LIU Lu was born in 1987. He received his B.S. degree from Army Artillery Academy of PLA in 2019 and M.S. degree in communication engineering from Army Engineering University of PLA in 2024. His research interests include non war military operation training theory. E-mail: 305485177@qq.com
Supported by:
This work was supported by the National Natural Science Foundation of China (72471240).

Abstract

Abstract:

When performing tasks, unmanned clusters often face a variety of strategy choices. One of the key issues in unmanned cluster tasks is the method through which to design autonomous collaboration and cooperative evolution mechanisms that allow for unmanned clusters to maximize their overall task effectiveness under the condition of strategic diversity. This paper analyzes these task requirements from three perspectives: the diversity of the decision space, information network construction, and the autonomous collaboration mechanism. Then, this paper proposes a method for solving the problem of strategy selection diversity under two network structures. Next, this paper presents a Moran-rule-based evolution dynamics model for unmanned cluster strategies and a vision-driven-mechanism-based evolution dynamics model for unmanned cluster strategy in the context of strategy selection diversity according to various unmanned cluster application scenarios. Finally, this paper provides a simulation analysis of the effects of relevant parameters such as the payoff factor and cluster size on cooperative evolution in autonomous cluster collaboration for the two types of models. On this basis, this paper presents advice for effectively addressing diverse choices in unmanned cluster tasks, thereby providing decision support for practical applications of unmanned cluster tasks.

Key words: unmanned cluster, strategy diversity, dynamic model, cooperative evolution

Zhenhai XIE, Minggang YU, Ming HE, Guoyou CHEN, Zheng ZHAI, Ziyu WANG, Lu LIU. Evolution mechanism of unmanned cluster cooperation oriented toward strategy selection diversity[J]. Journal of Systems Engineering and Electronics, 2025, 36(2): 462-482.

Figures/Tables 21

Fig 1

Fig 2

Fig 3

Table 1

Fig 4

Fig 5

Table 2

Fig 6

Fig 7

Fig 8

Fig 9

Fig 10

Fig 11

Fig 12

Fig 13

Fig 14

Fig 15

Fig 16

Fig 17

Fig 18

Fig 19

References 66

1	PENG Z H, WANG D, CHEN Z Y, et al Adaptive dynamic surface control for formations of autonomous surface vehicles with uncertain dynamics. IEEE Trans. on Control Systems Technology, 2013, 21 (2): 513- 520. doi: 10.1109/TCST.2011.2181513
2	MA P B, SUI J B, JI J, et al. Analysis of key issues in cooperative control of intelligent unmanned cluster systems. Tactical Missile Technology, 2022(4): 8. (in Chinese)
3	DUAN H B, QIU H X, FAN Y M Unmanned aerial vehicle close formation cooperative control based on predatory escaping pigeon-inspired optimization. Scientia Sinica Technologica, 2015, 45 (6): 559- 572. doi: 10.1360/N092015-00125
4	YU M G, CHEN J, HE M et al Cooperative evolution mechanism of multiclustered unmanned swarm on community networks. Scientia Sinica Technologica, 2023, 53 (2): 221- 242. doi: 10.1360/SST-2021-0350
5	GRIFFIN A S, WEST S A, BUCKLING A Cooperation and competition in pathogenic bacteria. Nature, 2004, 430 (7003): 1024- 1027. doi: 10.1038/nature02744
6	SZOLNOKI A, PERC M, SZABO G Defense mechanisms of empathetic players in the spatial ultimatum game. Physical Review Letters, 2012, 109 (7): 078701. doi: 10.1103/PhysRevLett.109.078701
7	HATANO Y, MESBAHI M Agreement over random networks. IEEE Trans. on Automatic Control, 2005, 50 (11): 1867- 1872. doi: 10.1109/TAC.2005.858670
8	LI C G, MAINI P K An evolving network model with community structure. Journal of Physics A: Mathematical and General, 2005, 38 (45): 9741- 9749. doi: 10.1088/0305-4470/38/45/002
9	ZHANG J L, ZHU Y Y, CHEN Z Q Evolutionary game dynamics of multiagent systems on multiple community networks. IEEE Trans. on Systems, Man, and Cybernetics: Systems, 2018, 50 (11): 4513- 4529.
10	GARRO A, MUHLHAUSER M, TUNDIS A et al Intelligent agents: multi-agent systems. Encyclopedia of Bioinformatics and Computational Biology, 2018, 315, 16.
11	HOLLAND J H. Hidden order: how adaptation builds complexity. Nature, 1995, 378(6556): 453−453.
12	DU J M, WU B, WANG L Aspiration dynamics and the sustainability of resources in the public goods dilemma. Physics Letters A, 2016, 380 (16): 1432- 1436. doi: 10.1016/j.physleta.2016.02.039
13	QUAN J, CHU Y Q, WANG X J Public goods with punishment and the evolution of cooperation. Systems Engineering Theory & Practice, 2019, 39 (1): 141- 149.
14	FLORES L S, FERNANDES H C M, AMARAL M A, et al Symbiotic behaviour in the public goods game with altruistic punishment. Journal of Theoretical Biology, 2021, 524, 110737. doi: 10.1016/j.jtbi.2021.110737
15	WOLFF I. What are the equilibria in public-good experiments? Economics Letters, 2017, 150: 83–85.
16	HAUERT C, DE MONTE S, HOFBAUER J, et al Volunteering as red queen mechanism for cooperation in public goods games. Science, 2002, 296 (5570): 1129- 1132. doi: 10.1126/science.1070582
17	BRANDT H, HAUERT C, SIGMUND K Punishment and reputation in spatial public goods games. Proceedings of the Royal Society of London Series B: Biological Sciences, 2003, 270 (1519): 1099- 1104. doi: 10.1098/rspb.2003.2336
18	HAUERT C, TRAULSEN A, BRANDT H, et al Via freedom to coercion: the emergence of costly punishment. Science, 2007, 316 (5833): 1905- 1907. doi: 10.1126/science.1141588
19	SANTOS F C, SANTOS M D, PACHECO J M Social diversity promotes the emergence of cooperation in public goods games. Nature, 2008, 454 (7201): 213- 216. doi: 10.1038/nature06940
20	PERC M, SZOLNOKI A Social diversity and promotion of cooperation in the spatial prisoner’s dilemma game. Physical Review E, 2008, 77 (1): 011904. doi: 10.1103/PhysRevE.77.011904
21	ZHONG W C, KOKUBO S, TANIMOTO J. How is the equilibrium of continuous strategy game different from that of discrete strategy game? Biosystems, 2012, 107(2): 88–94.
22	ZHONG W C, LIU J , ZHANG L. Evolutionary dynamics of continuous strategy games on graphs and social networks under weak selection. Biosystems, 2013, 111(2): 102–110.
23	FOTOUHI B, MOMENI N, ALLEN B, et al Evolution of cooperation on large networks with community structure. Journal of The Royal Society Interface, 2019, 16 (152): 20180677. doi: 10.1098/rsif.2018.0677
24	TKADLEC J, PAVLOGIANNIS A, CHATTERJEE K et al Population structure determines the tradeoff between fixation probability and fixation time. Communications Biology, 2019, 2 (1): 138. doi: 10.1038/s42003-019-0373-y
25	CHAKRABORTY M, CHOWDHURY S, CHAKRABORTY J, et al Algorithms for generating all possible spanning trees of a simple undirected connected graph: an extensive review. Complex & Intelligent Systems, 2018, 5 (3): 265- 281.
26	KILLINGBACK T, DOEBELI M The continuous prisoner’s Dilemma and the evolution of cooperation through reciprocal altruism with variable investment. The American Naturalist, 2002, 160 (4): 421- 438. doi: 10.1086/342070
27	IFTI M, KILLINGBACK T, DOEBELI M Effects of neighbourhood size and connectivity on the spatial continuous prisoner’s dilemma. Journal of Theoretical Biology, 2004, 231 (1): 97- 106. doi: 10.1016/j.jtbi.2004.06.003
28	CRESSMAN R, SONG J W, ZHANG B Y, et al Cooperation and evolutionary dynamics in the public goods game with institutional incentives. Journal of Theoretical Biology, 2012, 299, 144- 151. doi: 10.1016/j.jtbi.2011.07.030
29	HETZER M, SORNETTE D The co-evolution of fairness preferences and costly punishment. PLoS One, 2013, 8 (3): e54308. doi: 10.1371/journal.pone.0054308
30	WAKANO J Y A mathematical analysis on public goods games in the continuous space. Mathematical Biosciences, 2006, 201 (1/2): 72- 89.
31	GUAN J Y, WU Z X, WANG Y H Effects of inhomogeneous activity of players and noise on cooperation in spatial public goods games. Physical Review E, 2007, 76 (5): 056101. doi: 10.1103/PhysRevE.76.056101
32	SZABO G, HAUERT C Phase transitions and volunteering in spatial public goods games. Physical Review Letters, 2002, 89 (11): 118101. doi: 10.1103/PhysRevLett.89.118101
33	SZABO G, VUKOV J Cooperation for volunteering and partially random partnerships. Physical Review E, 2004, 69 (3): 036107. doi: 10.1103/PhysRevE.69.036107
34	AKCAY E Deconstructing evolutionary game theory: coevolution of social behaviors with their evolutionary setting. The American Naturalist, 2020, 195 (2): 315- 330. doi: 10.1086/706811
35	LIU A Z. Research of some cooperative evolutionary mechanisms based on evolutionary game theory. Beijing: University of Science and Technology Beijing, 2019. (in Chinese)
36	LI Y. Research of the dynamics of multi-strategy evolution on networks. Nanjing: Nanjing University of Aeronautics and Astronautics, 2015. (in Chinese)
37	YE W X, FAN S H Evolutionary snowdrift game with rational selection based on radical evaluation. Applied Mathematics and Computation, 2017, 294, 310- 317. doi: 10.1016/j.amc.2016.09.007
38	LUO C, JIANG Z P Coevolving allocation of resources and cooperation in spatial evolutionary games. Applied Mathematics and Computation, 2017, 311, 47- 57. doi: 10.1016/j.amc.2017.05.009
39	SHI D M, ZHUANG Y, WANG B H Group diversity promotes cooperation in the spatial public goods game. EPL, 2010, 90 (5): 1632- 1652.
40	SHI D M, ZHUANG Y, LI Y J, et al Depreciation of public goods in spatial public goods games. Journal of Statistical Mechanics: Theory and Experiment, 2011, 2011 (10): P10007. doi: 10.1088/1742-5468/2011/10/P10007
41	SHI D M, ZHUANG Y, WANG B H Effect of the depreciation of public goods in spatial public goods games. Physica A: Statistical Mechanics and its Applications, 2012, 391 (4): 1636- 1641. doi: 10.1016/j.physa.2011.10.006
42	DU J M, WU B, WANG L Aspiration dynamics in structured population acts as if in a well-mixed one. Scientific Reports, 2015, 5 (1): 8014. doi: 10.1038/srep08014
43	SUI X K, CONG R, LI K et al Evolutionary dynamics of N-person snowdrift game. Physics Letters A, 2015, 379 (45/46): 2922- 2934.
44	WU B, TRAULSEN A, GOKHALE C Dynamic properties of evolutionary multi-player games in finite populations. Games, 2013, 4 (2): 182- 199. doi: 10.3390/g4020182
45	WU B, ALTROCK P M, WANG L, et al Universality of weak selection. Physical Review E, 2010, 82 (4): 046106. doi: 10.1103/PhysRevE.82.046106
46	DU J M, WU B, ALTROCK P M, et al Aspiration dynamics of multi-player games in finite populations. Journal of the Royal Society Interface, 2014, 11 (94): 20140077. doi: 10.1098/rsif.2014.0077
47	SU Q, WANG L, STANLEY H E Understanding spatial public goods games on three-layer networks. New Journal of Physics, 2018, 20 (10): 103030. doi: 10.1088/1367-2630/aae6dd
48	LEE K H, CHAN C H, HUI P M, et al Cooperation in N-person evolutionary snowdrift game in scale-free Barabasi-Albert networks. Physica A: Statistical Mechanics and its Applications, 2008, 387 (22): 5602- 5608. doi: 10.1016/j.physa.2008.05.045
49	ZHENG D F, YIN H P, CHAN C H, et al Cooperative behavior in a model of evolutionary snowdrift games with N-person interactions. Europhysics Letters (EPL), 2007, 80 (1): 18002. doi: 10.1209/0295-5075/80/18002
50	ZHONG L X, ZHENG D F, ZHENG B, et al Networking effects on cooperation in evolutionary snowdrift game. Europhysics Letters (EPL), 2006, 76 (4): 724- 730. doi: 10.1209/epl/i2006-10323-2
51	LV J H, TAN S L. Games and evolutionary dynamics on complex networks. Beijing: Higher Education Press, 2019. (in Chinese)
52	YU M G , HE M, ZHANG D G, et al Scheme optimization for network information-centric system-of-systems based on multi-stage Bayesian Stackelberg game. Systems Engineering and Electronics, 2020, 42 (6): 1301- 1309.
53	YU M G, HE M, ZHANG D, et al. An approach to coordinated control of structured unmanned swarm based on evolutionary game. Proc. of the 3rd International Conference on Unmanned Systems, 2021: 220–226.
54	YU M G, NIU Y J, LIU X D, et al Adaptive dynamic reconfiguration mechanism of unmanned swarm topology based on an evolutionary game. Journal of Systems Engineering and Electronics, 2023, 34 (3): 598- 614.
55	LI P , WU Z H, YU M G, et al Strategy dominance mechanism of autonomous collaboration in unmanned swarm within the framework of public goods game. Journal of Systems Engineering and Electronics, 2023, 34 (5): 1252- 1266.
56	LIU Q, HE M, LIU J T, et al A mechanism for identifying and suppressing the emergent flocking behaviors of UAV swarms. Acta Electronica Sinica, 2019, 47, 374- 381.
57	YU M G, CHEN J, HE M, et al Collaborative mechanism of unmanned swarm in community network based on evolutionary game. Science China: Technological Sciences, 2023, 53 (2): 221- 242.
58	LIU Q, HE M. Research on countermeasures equipment demand and coping strategies for maritime small UAV swarms. Military Operations Research and Systems Engineering, 2019, 33(4): 59–65. (in Chinese)
59	YU M G, HE M, MA Z Y, et al Cooperative evolution mechanism of unmanned swarm within the framework of public goods game. Mathematical Problems in Engineering, 2021, 2021, 5575815.
60	LIU X D, HE M, YU M G, et al Research on UAV swarm ammunition distribution based on public goods game. Control and Decision, 2022, 37 (10): 2696- 2704.
61	BARABASI, ALBERT LASZLO, ALBERT R K. Emergence of scaling in random networks. Science, 1999, 286(5439): 509–512.
62	ANTAL T, TRAULSEN A, OHTSUKI H, et al Mutation-selection equilibrium in games with multiple strategies. Journal of Theoretical Biology, 2009, 258 (4): 614- 622. doi: 10.1016/j.jtbi.2009.02.010
63	NOWAK M A, SIGMUND K Evolutionary dynamics of biological games. Science, 2004, 303 (5659): 793- 799. doi: 10.1126/science.1093411
64	WILD G, TAYLOR P D Fitness and evolutionary stability in game theoretic models of finite populations. Proceedings of the Royal Society of London Series B: Biological Sciences, 2004, 271 (1555): 2345- 2349. doi: 10.1098/rspb.2004.2862
65	KINGMAN J F C On the genealogy of large populations. Journal of Applied Probability, 1982, 19 (A): 27- 43. doi: 10.2307/3213548
66	WAKELEY J Coalescent theory: an introduction. Systematic Biology, 2009, 58 (1): 162- 165. doi: 10.1093/schbul/syp004

Cluster cooperation	Evolutionary game
Effectiveness (capability) of unmanned platforms under specific spatial structures and strategies	Payment
Behaviors (decisions) of unmanned platforms	Strategy
Unmanned platform	Individual
Unmanned task cluster	Population
Strategy choices among unmanned platforms	Game
Proportion of individuals with different strategies in the cluster changing dynamically	Evolution
Proportion of individuals with different strategies in the cluster being stable	Evolutionarily stable
Relationships within unmanned clusters	Fully connected/ scale-free network
Unmanned platform of the study object	Individual in focus
Strategies from which unmanned platforms in a cluster can choose	Collection of cooperative strategies

Number	Parameter/variable	Meaning	Practical significance
1	$ N $	Population	Unmanned task cluster
2	$ k_{x} $	Degree of individual $ x $	Unmanned task unit’s number of neighbors
3	$ r $	Gain factor	Payoff multiplication factor of unmanned task unit during participation in cooperation
4	$ C_{x} $	Individuals participate in each cluster amount of investment	Payment by an unmanned task unit in cooperation with all of its neighboring task units (the cluster to which the neighbors belong)
5	$ f_{x} $	Payoff for individual $ x $ in the game	Cooperative payoff for an unmanned task unit in a cluster centered on its neighbors
6	$ f_{x, y} $	Game payoff for individual $ x $ in the cluster centered on individual $ y $	Payoff for task unit $ x $ after collaboration with the cluster centered on task unit $ y $, with unmanned task unit $ x $ as the focus
7	$ F_{x} $	Game payoff of individual $ x $	Specific payoff of the same task unit in multiparty, multistrategy cooperation
8	$ s_{i} $	Strategy	Cooperative behavior in which unmanned task units are willing to contribute resources to the cluster
9	$ w $	Selection intensity	Activity of the unmanned task unit in t strategy selection
10	$ \alpha $	Vision level	Expectation of the unmanned combat unit to choose strategies depending on the battlefield environment
11	$ S $	Strategy set	Number of all actions of unmanned task platforms participating in cooperative games
12	$ [a_{ij}] $	Payment value matrix	Payoff matrix generated by the cooperation between unmanned platform A adopting strategy i and unmanned platform B adopting strategy j
13	$ R $	Average cluster investment level	Overall cooperative effectiveness of unmanned cluster autonomous collaboration
