Modeling optimal air traffic rights resource allocation

doi:10.23919/JSEE.2025.000070

Abstract

Abstract:

International freedom of the air (traffic rights) is a key resource for airlines to carry out international air transport business. An efficient and reasonable traffic right resource allocation within a country between airlines can affect the quality of a country’s participation in international air transport. In this paper, a multi-objective mixed-integer programming model for traffic rights resource allocation is developed to minimize passenger travel mileages and maximize the number of traffic rights resources allocated to hub airports and competitive carriers. A hybrid heuristic algorithm combining the genetic algorithm and the variable neighborhood search is devised to solve the model. The results show that the optimal allocation scheme aligns with the principle of fairness, indicating that the proposed model can play a certain guiding role in and provide an innovative perspective on traffic rights resource allocation in various countries.

Key words: air transport, air traffic right (ATR), genetic algorithm, variable neighborhood search, mixed integer programming formulation

Zhishuo LIU, Yi’nan CHENG, Yanhua LI, Danyang SHEN. Modeling optimal air traffic rights resource allocation[J]. Journal of Systems Engineering and Electronics, 2025, 36(3): 778-790.

Figures/Tables 11

Table 1

Table 2

Fig 1

Fig 2

Fig 3

Table 3

Table 4

Table 5

Table 6

Table 7

Table 8

References 33

1	ONGURU J O N. Limitations on the exercise of the first freedom traffic rights in international air transportation in common law jurisdictions. Montreal: McGill University, 1982.
2	BARTLIK M. The distribution of air traffic rights. Master, Montreal : McGill University, 2004.
3	DONG X. A study on the exchange of traffic rights. Beijing: China University of Political Science and Law, 2009.
4	SUNG P K, NA C J The legal review of the traffic right allocation at the aviation law. Kyung Hee Law Journal, 2010, 45 (3): 335- 361.
5	HUANG Y H. A study of legal issues related with the exchange of fifth air traffic rights between China and ASEAN. Shanghai: East China University of Political Science and Law, 2020.
6	YANG S G, YANG Z Y, WEI Z X The opening of traffic rights and the construction of core competitiveness of Chinese airlines. Journal of Commercial Economics, 2008, 27 (34): 97- 98.
7	YANG S G, YANG Z Y The impact of opening air traffic rights on the regional economic security and countermeasures. Reformation & Strategy, 2010, 26 (11): 118- 121.
8	XIANG J Y Openning air traffic rights: cause, evolution and performance. Reformation & Strategy, 2010, 26 (7): 46- 48, 53.
9	RAO Y, ZHONG C. The impact of the opening of fifth traffic rights on the development of inbound tourism in China. Chinese & Foreign Entrepreneurs, 2015, 32(36): 24, 26.
10	LEE J W, HORTON W. Fifth freedom traffic rights: formidable threat or theoretical concern? Air and Space Law, 2018, 43(3): 303–318.
11	YIN P W, XU J Analysis of the influence mechanism of the fifth traffic rights on the aviation logistics industry—taking Shaanxi Province as an example. Aeronautical Finance and Accounting, 2019, 1 (4): 47- 52.
12	CHOI Y J, PARK J H Analysis on the exchange value of traffic rights between korea and china strategic route: focusing on incheon international airport. Korea Trade Review, 2019, 44 (1): 159- 175.
13	CHONG D P A study for the global competitive strategies of Korean low-cost carrier. The e-Business Studies, 2019, 20 (1): 273- 288. doi: 10.20462/TeBS.2019.2.20.1.273
14	CHOI Y, LEE J S A study on the relation between LCCS’ market penetration and additional demand growth: the strategic choices for expanding open skies to Chinese local cities. Journal of Tourism Management Research, 2020, 24 (7): 567- 592. doi: 10.18604/tmro.2020.24.7.27
15	ZHAO J, CHEN X M, LIU Z S, et al Modeling and analysis of sequential reciprocal game problem of bilateral negotiation for air traffic rights resources. Journal of Harbin Institute of Technology, 2022, 54 (3): 1- 11.
16	ZHANG A, ZHANG Y M Issues on liberalization of air cargo services in international aviation. Journal of Air Transport Management, 2002, 8 (5): 275- 287. doi: 10.1016/S0969-6997(02)00008-X
17	DAVID W S, JOHN F O The impact of air policy on incoming tourist traffic: the contrasting cases of the Caribbean Community and the Middle-East. Journal of Transport Geography, 2011, 19 (2): 265- 274. doi: 10.1016/j.jtrangeo.2010.04.004
18	ZHAO J, CHEN X M. A data-driven comprehensive evaluation method for scarce international traffic rights resource allocation. Proc. of the IEEE 2nd International Conference on Civil Aviation Safety and Information Technology, 2020: 172−175.
19	ZHAO J, LIU Z S, LI Q Y, et al Optimal allocation of scarce passenger air traffic right resources. Journal of Nanjing University of Aeronautics & Astronautics, 2021, 53 (6): 872- 880.
20	DONG X. Research on right of way exchange. Beijing: Intellectual Property Press, 2010.
21	ZHANG Y On air rights exchange and air rights economy. Shanghai Economic Research, 2017, (3): 103- 108.
22	LI Y. China’s foreign air rights exchange: status quo, problems and improvement. Journal of Beijing University of Aeronautics and Astronautics (Social Science Edition). https://doi.org/10.13766/j.bhsk.1008-2204.2021.0864. (in Chinese)
23	International Civil Aviation Organization. Manual on the regulation of international air transport. 2nd ed. https://www.icao.int/Meetings/a39/Documents/Provisional_Doc_9626.pdf.
24	EBERY J, KRISHNAMOORTHY M, ERNST A, et al The capacitated multiple allocation hub location problem: formulations and algorithms. European Journal of Operational Research, 2000, 120 (3): 614- 631. doi: 10.1016/S0377-2217(98)00395-6
25	MAHMUTOGULLARI A I, KARA B Y Hub location under competition. European Journal of Operational Research, 2016, 250 (1): 214- 225. doi: 10.1016/j.ejor.2015.09.008
26	SRINIVAS N, DEB K Multiobjective function optimization using nondominated sorting genetic algorithms. Evolutionary Computation, 1994, 2 (3): 1301- 1308.
27	LIU Z S, LIN S M, LI H Production scheduling of regional industrial clusters based on customization oriented smart garment ecosystem. International Journal of Crowd Science, 2023, 7 (1): 1- 9. doi: 10.26599/IJCS.2022.9100024
28	FAN C L, FU Q, LONG G Z, et al Hybrid artificial bee colony algorithm with variable neighborhood search and memory mechanism. Journal of Systems Engineering and Electronics, 2018, 29 (2): 405- 414. doi: 10.21629/JSEE.2018.02.20
29	LIU Z S, ZUO X Q, ZHOU M C, et al Electric vehicle routing problem with variable vehicle speed and soft time windows for perishable product delivery. IEEE Trans. on Intelligent Transportation Systems, 2023, 24 (6): 6178- 6190. doi: 10.1109/TITS.2023.3249403
30	LIU Z S, TIAN F, LI L D, et al Product search algorithm based on improved ant colony optimization in a distributed network. International Journal of Crowd Science, 2022, 6 (3): 128- 134. doi: 10.26599/IJCS.2022.9100016
31	ANDARYAN A, MOUSIGHICHI K, HAFFARINASAB N A heuristic approach to the stochastic capacitated single allocation hub location problem with Bernoulli demands. European Journal of Operational Research, 2024, 312 (3): 954- 968. doi: 10.1016/j.ejor.2023.07.015
32	WANG B, ZHANG P F, HE Y F, et al Scenario-oriented hybrid particle swarm optimization algorithm for robust economic dispatch of power system with wind power. Journal of Systems Engineering and Electronics, 2022, 33 (5): 1143- 1150. doi: 10.23919/JSEE.2022.000110
33	VINCENT F, REDI A, HIDAYAT Y, et al. A simulated annealing heuristic for the hybrid vehicle routing problem. Applied Soft Computing, 2017, 5: 119−132.

Type	Notation	Description
Set	P	Set of passengers’ origins, $ p\in P $
	Q	Set of passengers’ destinations, $ q\in Q $
	R	Set of carriers, $ r\in {{R}} $
	K	Set of flights, $ k\in K $
	C_n, V_n	Sets of HS and FS airports in the nth region, respectively
	C	$C = {C_1} \cup {C_2} \cup \cdots \cup {C_{{N_{{r}}}}}$
	V	$V = {V_1} \cup {V_2} \cup \cdots \cup {V_{{N_{{r}}}}}$
Parameter	l_pj	Distance between origin p and HS airport j
	l_ji	Distance between HS airport j and FS airport i
	l_iq	Distance between FS airport i and destination q
	p_j	Volume of transit passengers at airport j
	β_r	Competitiveness of carrier r
	θ_rj	Market share of carrier r at airport j
	ω₁, ω₂, ω₃	Weight of the multiple objective functions
	D_r	Operational capacity of carrier r (i.e., the maximum number of flights it can put into operation per week)
	M_pq	Number of passengers from origin p to destination q
	a_n	Restriction on the number of flights operated per week for the nth region (i.e., the route capacity)
	L⁺, L⁻	Maximum/minimum passenger load of each flight
	N	Limit on the number of enabled carriers
Variable	w_r	w_r =1 if carrier r is enabled; otherwise, 0
	x_jirk	x_jirk =1 if flight k is operated by carrier r to fly the route j → i; otherwise, 0
	z_pqjirk	Integer variable, number of passengers (whose trip’s origin is p and whose destination is q) taking flight k operated by carrier r to fly route j → i

Perspective	Objective	Objective function formulation	Explanation	Principles to respond
Passengers	To enable passengers to travel more efficiently and conveniently	$ \min \displaystyle\sum {{z_{pqjirk}}\left( {{l_{pj}} + {l_{ji}} + {l_{iq}}} \right)} $	Minimizing passengers’ total travel time and distance	Maximizing public interests
Airports	To build international aviation hubs	$ \min \displaystyle\sum {\frac{{{x_{jirk}}}}{{{p_j}}}} $	The higher hub status an airport has, the more ATR resources it obtains	Promoting hub construction
Carriers	To sustain large network carriers	$ \min \displaystyle\sum {\frac{{{x_{jirk}}}}{{{\beta _r}{\theta _{rj}}}}} $	The more competitive the carrier and higher market share a carrier holds at an airport, the more ATR resources it obtains	Guiding orderly and moderate competition among carriers; maximizing ATR resource use; enhancing comprehensive carrier competitiveness

Air route	Carrier	Number of flights	Region
PEK-CDG	CA	27	1
CAN-CDG	CZ	12	1
PVG-CDG	MU	21	1
CTU-CDG	CA	4	2
KMG-CDG	MU	9	2
XIY-CDG	MU	5	2
SZX-CDG	CZ	3	2
PEK-NCE	CA	1	3
PVG-NCE	MU	1	3
PVG-LYS	MU	1	3

Region	Capacity	Residual		Carrier	Air route	Number of flights
Region	Capacity	Plan A	Plan B	Carrier	Air route	Plan A	Plan B
1: PEK/PVG/CAN to CDG	60	0	0	CA	PEK-CDG	27	21
				CZ	PEK-CDG	0	7
				CA	PVG-CDG	0	7
				MU	PVG-CDG	21	18
				CZ	CAN-CDG	12	7
2: HS airports except PEK/PVG/CAN to CDG	31	8	4	CA	CTU-CDG	4	3
				MU	KMG-CDG	9	3
				MU	TAO-CDG	0	3
				MU	NKG-CDG	0	4
				HU	XIY-CDG	0	3
				MU	XIY-CDG	5	0
				HU	CKG-CDG	0	2
				HU	KWE-CDG	0	1
				HU	SZX-CDG	0	3
				CZ	SZX-CDG	3	0
				MF	FOC-CDG	0	5
3: HS airports to FS airports except CDG	35	30	28	CA	PEK-NCE	1	3
				FM	PVG-NCE	0	4
				MU	PVG-NCE	1	0
				MU	PVG-LYS	1	0
