Off-grid DOA estimation based on coherent accumulation and weighted block sparse Bayesian

doi:10.23919/JSEE.2025.000164

Journal of Systems Engineering and Electronics ›› 2026, Vol. 37 ›› Issue (2): 327-336.doi: 10.23919/JSEE.2025.000164

• ELECTRONICS TECHNOLOGY •

Off-grid DOA estimation based on coherent accumulation and weighted block sparse Bayesian

Ankang REN¹^,²^,*(), Qi WU¹(), Pingye LIANG¹^,²(), Yuanyuan XU³()

¹School of Electronics and Information Engineering, Beihang University, Beijing 100191, China
²Beijing Electro-Mechanical Engineering Institute, Beijing 100074, China
³School of Information Science and Engineering, Harbin Institute of Technology (Weihai), Weihai 264209, China

Received:2025-06-04 Accepted:2025-11-05 Online:2026-04-18 Published:2026-04-30
Contact: Ankang REN E-mail:renankang@163.com;qwu@buaa.edu.cn;pingyeliang@126.com;xuyuanyuan626@163.com
About author:
REN Ankang was born in 1986. He received his M.S. degree in electromagnetic ﬁeld and microwave technique at Northwestern Polytechnical University, Xi’an, China in 2012. He is currently a research professor at Beijing Electro-Mechanical Engineering Institute. His research interests include broadband antennas, conformal array, and polarization sensitive array signal processing. E-mail: renankang@163.com

WU Qi was born in 1983. He received his B.S. degree from East China Normal University, Shanghai, China, and Ph.D. degree from Shanghai Jiao Tong University, Shanghai, China, both in electrical engineering, in 2004 and 2009, respectively. He is currently a professor at School of Electronics and Information Engineering, Beihang University. His research interests include broadband antennas, computational electromagnetics, and related EMC topics. E-mail: qwu@buaa.edu.cn

LIANG Pingye was born in 1992. He received his M.E. degree from Guilin University of Electronic Technology, Guilin, China, in 2018. He is currently an engineer at Beijing Electro-Mechanical Engineering Institute. His research interests include low-scattering broadband antenna and phased array antenna testing. E-mail: pingyeliang@126.com

XU Yuanyuan was born in 2000. She received the B.E. degree in communication Engineering from Yanbian University, Yanbian, China in 2022. She is currently a Master’s degree candidate at Harbin Institute of Technology (Weihai) . Her research interest is array signal processing. E-mail: xuyuanyuan626@163.com
Supported by:
This work was supported by the National Natural Science Foundation of China (U2141230).

Abstract

Abstract:

To deal with the problem that the block sparse Bayesian algorithm exists in grid estimation, an off-grid weighted block sparse Bayesian algorithm is proposed based on coherent accumulation. The algorithm first uses the signal characteristics to coherently accumulate the polarization-sensitive array received data to enhance the signal-to-noise ratio (SNR); then the first-order Taylor expansion of the steering vector is performed, and an off-grid real-valued model is introduced by improving the block structure; then the weighting vectors are introduced to accelerate the iteration of the algorithm and reduce the number of iterations; and finally, the solution of the off-grid parameters is achieved by iterative optimization of the parameters. Compared with the traditional block sparse Bayesian learning (BSBL) algorithm, the method iterates faster and achieves efficient joint off-grid polarization-DOA estimation. Simulation results show the effectiveness of the algorithm.

Key words: direction of arrival estimation, weighted block sparse Bayesian, coherent accumulation, off-grid

Ankang REN, Qi WU, Pingye LIANG, Yuanyuan XU. Off-grid DOA estimation based on coherent accumulation and weighted block sparse Bayesian[J]. Journal of Systems Engineering and Electronics, 2026, 37(2): 327-336.

Figures/Tables 7

Fig 1

Fig 2

Fig 3

Fig 4

Fig 5

Fig 6

Table 1

References 32

1	KIMIA S, M Z K A joint TOA and DOA acquisition and tracking approach for positioning with LTE signals. IEEE Trans. on Signal Processing, 2021, 69, 2689- 2705. doi: 10.1109/TSP.2021.3068920
2	BIRKENES I T L, ANDREAS A, EDGAR R H Data-driven autocalibration for swath sonars. IEEE Journal of Oceanic Engineering, 2021, 46 (3): 979- 987. doi: 10.1109/JOE.2020.3036184
3	NINGJUN R, HAN W, FANGQING W, et al DOA estimation in B5G/6G: trends and challenges. Sensors, 2022, 22 (14): 5125. doi: 10.3390/s22145125
4	BIN L, GUOPING H, HAO Z, et al Coherent signal DOA estimation for MIMO radar under composite background of strong interference and non-uniform noise. Sensors, 2022, 22 (24): 9833. doi: 10.3390/s22249833
5	WANG B W, LI N X, YIN H, et al. Performance evaluation of polarization sensitive array based DOA estimation. Proc. of the 25th International Symposium on Wireless Personal Multimedia Communications, 2022: 33−37.
6	GERSTOFT P, MECKLENBRAUKER C F, XENAKI A, et al Multisnapshot sparse Bayesian learning for DOA. IEEE Signal Processing Letters, 2016, 23 (10): 1469- 1473.
7	HYDER M M, MAHATA K Direction-of-arrival estimation using a mixed norm approximation. IEEE Trans. on Signal Processing, 2010, 58 (9): 4646- 4655. doi: 10.1109/TSP.2010.2050477
8	LI X, MA X C, YAN S F, et al Single snapshot DOA estimation by compressive sampling. Applied Acoustics, 2013, 74, 926- 930. doi: 10.1016/j.apacoust.2013.01.005
9	MALLAT S G, ZHANG Z F Matching pursuits with time-frequency dictionaries. IEEE Trans. on Signal Processing, 1993, 41 (12): 3397- 3415. doi: 10.1109/78.258082
10	SU L, GU S H, DENG G P DOA estimation via sparse L-shaped array and orthogonal matching pursuit. Journal of Terahertz Science and Electronic Information, 2024, 22 (3): 345- 352.
11	MALIOUTOV D, CETIN M, WILLSKY A S A sparse signal reconstruction perspective for source localization with sensor arrays. IEEE Trans. on Signal Processing, 2005, 53 (8): 3010- 3022. doi: 10.1109/TSP.2005.850882
12	TIPPING M E Sparse Bayesian learning and the relevance vector machine. Journal of Machine Learning Research, 2001, 1 (Jun): 211- 244.
13	WIPF D P, RAO B D Sparse Bayesian learning for basis selection. IEEE Trans. on Signal Processing, 2004, 52 (8): 2153- 2164. doi: 10.1109/TSP.2004.831016
14	HE Y, JOSEPH G Bayesian algorithms for Kronecker-structured sparse vector recovery with application to IRS-MIMO channel estimation. IEEE Trans. on Signal Processing, 2025, 73, 142- 157. doi: 10.1109/TSP.2024.3416543
15	ZHANG Z L, RAO B D. Recovery of block sparse signals using the framework of block sparse Bayesian learning. Proc. of the IEEE International Conference on Acoustics, Speech and Signal Processing, 2012: 3345−3348.
16	HAGHIGHATPANAH N, GOHARY R H. Improved Bayesian learning algorithms for recovering block sparse signals with known and unknown borders. Proc. of the International Conference on Communications, Signal Processing, and their Applications, 2022. DOI: 10.1109/ICCSPA55860.2022.10019156.
17	KORKI M, ZHANG J, ZHANG C, et al. An iterative Bayesian algorithm for block-sparse signal reconstruction. Proc. of the IEEE International Conference on Acoustics, Speech and Signal Processing, 2015: 2174−2178.
18	ZHANG Z, RAO B D Extension of SBL algorithms for the recovery of block sparse signals with intra-block correlation. IEEE Trans. on Signal Processing, 2011, 59 (3): 1309- 1321. doi: 10.1109/TSP.2010.2097254
19	DAI J, SO H C Real-valued sparse Bayesian learning for DOA estimation with arbitrary linear arrays. IEEE Trans. on Signal Processing, 2021, 69, 4977- 4990. doi: 10.1109/TSP.2021.3106741
20	WANG H, WANG F A multilayer joint regularized block sparse Bayesian algorithm with space–time structured prior learning function. IEEE Trans. on Geoscience and Remote Sensing, 2024, 62, 5105312.
21	LI B B, BAI W X, et al BSBL-based DOA and polarization estimation with linear spatially separated polarization sensitive array. Wireless Personal Communications, 2019, 109 (3): 2051- 2065. doi: 10.1007/s11277-019-06667-6
22	LI J Q, DONG X D, SHI X L, et al An enhanced direct position determination of non-circular sources via sparse Bayesian inference and grid refinement strategy. Digital Signal Processing, 2024, 151, 104564. doi: 10.1016/j.dsp.2024.104564
23	GUO Q J, XIN Z N, ZHOU T, et al Off-grid space alternating sparse Bayesian learning. IEEE Trans. on Instrumentation and Measurement, 2023, 72, 1002310.
24	FU H S, DAI F Z, HONG L Off-grid error calibration for DOA estimation based on sparse Bayesian learning with weighted sinc interpolation. IEEE Trans. on Vehicular Technology, 2023, 72 (12): 16293- 16307. doi: 10.1109/TVT.2023.3298965
25	YOU K Y, YANG L S, LIU Y L, et al Adaptive grid multiple sources localization based on sparse Bayesian learning. Journal of Electronics & Information Technology, 2018, 40, 2150- 2157.
26	YIN S J, YANG Y, XIA J F, et al Compressive spherical beamforming based on fast off-grid sparse Bayesian inference. Applied Acoustics, 2024, 225, 110190. doi: 10.1016/j.apacoust.2024.110190
27	YANG Z, XIE L H, ZHANG C S Off-grid direction of arrival estimation using sparse Bayesian inference. IEEE Trans. on Signal Processing, 2013, 61 (1): 38- 43. doi: 10.1109/TSP.2012.2222378
28	HE W C, LIANG L K, YUNG X C Sparse Bayesian DOA estimation under coherent source conditions. Telecommunication Technology, 2021, 61 (8): 993- 998.
29	ZHANG Y, JING X L, JIANG Z J An off-grid DOA estimation algorithm based on sparse Bayesian learning. Radar Sci. Technology, 2024, 22 (1): 35- 42.
30	HUANG H P, SO H C, ZOUBIR A M Off-grid direction-of-arrival estimation using second-order Taylor approximation. Signal Processing, 2022, 196, 108513. doi: 10.1016/j.sigpro.2022.108513
31	WANG Y, TIAN Z IVDST: a fast algorithm for atomic norm minimization in line spectral estimation. IEEE Signal Processing Letters, 2018, 25 (11): 1715- 1719. doi: 10.1109/LSP.2018.2870539
32	YANG J, YANG Y X Sparse Bayesian DOA estimation using hierarchical synthesis Lasso priors for off-grid signals. IEEE Trans. on Signal Processing, 2020, 68, 872- 884. doi: 10.1109/TSP.2020.2967665

BW (LFM)/MHz	θ/(°)	γ/(°)	η/(°)
0	0.149	1.087	6.203
0.1	0.221	2.594	12.732
0.5	0.278	4.109	22.806
