Re-entry gliding vehicle trajectory prediction based on maneuver detection

doi:10.23919/JSEE.2026.000014

Journal of Systems Engineering and Electronics ›› 2026, Vol. 37 ›› Issue (1): 9-17.doi: 10.23919/JSEE.2026.000014

• PERCEPTION, CONTROL, AND DECISION-MAKING OF EMBODIED INTELLIGENT SYSTEMS • Previous Articles Next Articles

Re-entry gliding vehicle trajectory prediction based on maneuver detection

Yudong HU(), Maofeng PANG(), Qingfeng DU(), Changsheng GAO()

School of Astronautics, Harbin Institute of Technology, Harbin 150001, China

Received:2025-11-12 Online:2026-02-18 Published:2026-03-09
Contact: Yudong HU E-mail:huyudong@hit.edu.cn;24s118196@stu.hit.edu.cn;duqingfeng0208@163.com;gaocs@hit.edu.cn
About author:
HU Yudong was born in 1991. He received his M.S. degree in motion control and navigation systems from Samara State Aerospace University, Russia, in 2018, and Ph.D. degree in aerospace science and technology from Harbin Institute of Technology, China, in 2022. He is currently an assistant professor with Harbin Institute of Technology. His research interests include aircraft trajectory planning, target tracking, and trajectory prediction. E-mail: huyudong@hit.edu.cn

PANG Maofeng was born in 2002. He received his B.S. degree in aerospace engineering from Central South University, Changsha, China, in 2024. He is currently pursuing his M.S. degree in mechanical engineering (aerospace engineering) with the School of Astronautics, Harbin Institute of Technology, China. His research interests include target tracking and trajectory prediction. E-mail: 24s118196@stu.hit.edu.cn

DU Qingfeng was born in 1998. He received his M.S. degree in aerospace engineering from Harbin Institute of Technology, China, in 2021, and Ph.D. degree in aerospace science and technology from the School of Astronautics, Harbin Institute of Technology. His research interests include moving-mass control and pursuit-evasion game. E-mail: duqingfeng0208@163.com

GAO Changsheng was born in 1978. He received his M.S. and Ph.D. degrees in flight vehicle design from Harbin Institute of Technology, China, in 2002 and 2007, respectively. He is currently a professor and a Ph.D. supervisor with Harbin Institute of Technology. His research interests include guidance, navigation, control of aircraft, and moving-mass control. E-mail: gaocs@hit.edu.cn
Supported by:
This work was supported by the National Natural Science Foundation of China (12302056) and the Postdoctoral Fellowship Program of China Postdoctoral Science Foundation (GZC20233445).

Abstract

Abstract:

Re-entry gliding vehicles exhibit high maneuverability, making trajectory prediction a key factor in the effectiveness of defense systems. To overcome the limited fitting accuracy of existing methods and their poor adaptability to maneuver mode mutations, a trajectory prediction method is proposed that integrates online maneuver mode identification with dynamic modeling. Characteristic parameters are extracted from tracking data for parameterized modeling, enabling real-time identification of maneuver modes. In addition, a maneuver detection mechanism based on higher-order cumulants is introduced to detect lateral maneuver mutations and optimize the use of historical data. Simulation results show that the proposed method achieves accurate trajectory prediction during the glide phase and maintains high accuracy under maneuver mutations, significantly enhancing the prediction performance of both three-dimensional trajectories and ground tracks.

Key words: trajectory prediction, re-entry gliding vehicle, maneuver mode identification, maneuver detection

Yudong HU, Maofeng PANG, Qingfeng DU, Changsheng GAO. Re-entry gliding vehicle trajectory prediction based on maneuver detection[J]. Journal of Systems Engineering and Electronics, 2026, 37(1): 9-17.

Figures/Tables 7

Fig 1

Fig 2

Fig 3

Fig 4

Table 1

Table 2

Fig 5

References 32

1	ZHANG R, LI H F, ZHANG R Linear near-equilibrium glide model for unpowered entry trajectory control. Aerospace Science and Technology, 2017, 70, 526- 533. doi: 10.1016/j.ast.2017.08.017
2	MA S D, YANG Y X, YANG H, et al Trajectory optimization of hypersonic vehicle considering the quasi-static assumption of pitch motion. Aerospace Science and Technology, 2024, 146, 108969. doi: 10.1016/j.ast.2024.108969
3	SHAO L, LEI H M, ZHAO J Research progress on trajectory prediction methods for near-space hypersonic vehicles. Aerospace Weapons, 2021, 28 (2): 34- 39.
4	YAO Y, ZHENG T Y, HE F H, et al Several hot issues and challenges in terminal guidance of flight vehicles. Acta Aeronautica et Astronautica Sinica, 2015, 36 (8): 2696- 2716.
5	LIANG X G, TIAN H L Development status of near-space hypersonic vehicles and analysis of their defense issues. Aerospace Weapons, 2016, (4): 3- 10.
6	CHEN W X, HU Y D, GAO C S, et al Luring cooperative capture guidance strategy for the pursuit—evasion game under incomplete target information. Astrodynamics, 2024, 8, 675- 688. doi: 10.1007/s42064-024-0224-6
7	ZHANG H Trajectory prediction of glide vehicle based on typical control law. Modern Defense Technology, 2017, 45 (4): 112- 118.
8	CHEN N H, ZHAO L Y, YONG E M, et al Trajectory sequence prediction algorithm for maneuvering hypersonic glide targets. Aeronautical Armament, 2021, 28 (2): 40- 48.
9	ZHAO Y J, YANG H W, LI S et al. On-board modeling of gravity fields of elongated asteroids using Hopfield neural networks. Astrodynamics, 2023, 7, 101- 114.
10	CHEN J, SUN X, XUE Z, et al Target intention prediction of air combat based on Mog-GRU-D network under incomplete information. Journal of Systems Engineering and Electronics, 2025, 36 (4): 972- 984.
11	LI J, HE Y C, SHAO L, et al Reentry glide vehicle trajectory prediction method via multidimensional intention fusion. Aerospace Science and Technology, 2025, 159, 109960. doi: 10.1016/j.ast.2025.109960
12	ZHANG P, WU D, BAOYIN H G Real-time hybrid method for maneuver detection and estimation of non-cooperative space targets. Astrodynamics, 2024, 8, 437- 453. doi: 10.1007/s42064-024-0203-y
13	ZHANG K, XIONG J J Multi-layer recursive trajectory prediction for hypersonic glide targets. Modern Defense Technology, 2018, 46 (4): 92- 98.
14	WANG K Y, XU Z, TANG S, et al A ballistic prediction method for near-space short-range glide vehicles based on flight mission. Journal of Astronautics, 2021, 42 (1): 50- 60.
15	SUN L H, YANG B Q, MA J Trajectory prediction in pipeline form for intercepting hypersonic gliding vehicles based on LSTM. Chinese Journal of Aeronautics, 2023, 36 (5): 421- 433. doi: 10.1016/j.cja.2023.02.017
16	RAO C V, RAWLINGS J B, LEE J H Constrained linear state estimation—a moving horizon approach. Automatica, 2001, 37 (10): 1619- 1628.
17	XU X W. Research of the Sins/Beidou integrated navigation filtering algorithm based on moving horizon estimation. Huhehaote: Inner Mongolia University, 2020. (in Chinese)
18	LU H K, WANG P, FU X W, et al A first order generalized pseudo-Bayesian method based on moving horizon estimation for surrounding vehicle states estimation in complex environments. Measurement, 2023, 213, 112678. doi: 10.1016/j.measurement.2023.112678
19	SUN C Q, XIAO Y, YE D, et al Fault tolerant model predictive control of satellite pose integration via moving horizon estimation. Journal of Astronautics, 2023, 44 (6): 885- 894.
20	JIAO Z Q, LI W H, WANG P A multi model method of tracking maneuvering target based on multiple model and moving horizon estimation. Journal of Air Force Engineering University (Natural Science Edition), 2016, 17 (2): 15- 20.
21	ZHANG J B, XIONG J J, LAN X H, et al An intelligent trajectory prediction method for hypersonic glide vehicles. Journal of Astronautics, 2022, 43 (4): 413- 422.
22	LI M J, ZHOU C J, LEI H M, et al Intelligent trajectory prediction algorithm for reentry glide targets based on control parameter estimation. Systems Engineering and Electronics, 2023, 45 (1): 221- 233.
23	REN J H, WU X, LIU Y, et al Long-term trajectory prediction of hypersonic glide vehicle based on physics-informed transformer. IEEE Trans. on Aerospace and Electronic Systems, 2023, 59 (6): 9551- 9561.
24	XIE Y F, ZHUANG X B, XI Z P, et al Dual-channel and bidirectional neural network for hypersonic glide vehicle trajectory prediction. IEEE Access, 2021, 9, 92913- 92924.
25	TAN J Q, LIU T P, JIANG W D, et al Azimuth-dimensional RCS prediction method based on physical model priors. Journal of Systems Engineering and Electronics, 2025, 36 (1): 1- 14.
26	HU G S. Digital signal processing theory, algorithms, and implementation. 2nd ed. Beijing: Tsinghua University Press, 2003. (in Chinese)
27	WANG X T, CAI Z M Moving target detection method based on higher-order statistics in reverberation background. Journal of National University of Defense Technology, 2020, 42 (2): 135- 141.
28	SONG L P, JI H B, GAO X B A new method for target maneuver detection based on higher-order cumulants. Acta Electronica Sinica, 2004, 1, 154- 156.
29	TANG R. Trajectory tracking control of hypersonic vehicles based on adaptive dynamic programming. Changsha: Central South University, 2023. (in Chinese)
30	QIU J L. Trajectory tracking and prediction of near-space hypersonic glide vehicles. Harbin: Harbin Institute of Technology, 2023. (in Chinese)
31	WU P Y, ZHANG Y, LI J, et al A real-time maneuver detection method for low data rate. Acta Astronautica, 2025, 237, 289- 299.
32	HE Z Y, YANG Y, CHEN W, et al A multi-frame hybrid integration method combined with differential evolution for maneuvering target detection with GNSS-based passive radar. Advances in Space Research, 2025, 76 (1): 110- 127.

Prediction horizon	Time/s
Prediction horizon	50	100	150	200
Longitudinal trajectory error	0.932	2.360	3.165	2.917
Ground track error	1.953	10.181	27.201	56.173
Overall error	2.916	9.729	26.026	54.318

Prediction horizon	Time/s
Prediction horizon	50	100	150	200
Longitudinal trajectory error	0.393	0.6749	0.877	1.232
Ground track error	1.176	3.755	9.556	20.151
Overall error	1.318	3.902	9.663	20.305
